STANDARD 20' | | | | INSIDE LENGTH | 19'4" | 5.89 m | INSIDE WIDTH | 7'8" | 2.33 m | INSIDE HEIGHT | 7'10" | 2.38 m | DOOR WIDTH | 7'8" | 2.33 m | DOOR HEIGHT | 7'6" | 2.28 m | CAPACITY | 1,172 ft³ | 33.18 m³ | TARE WEIGHT | 4,916 lb | 2,229 kg | MAX. CARGO* | 47,999 lb | 21,727 kg | *Max Cargo weight indicates container capacity and not legal over the road weight |
| |
| | STANDARD 40' | HIGH CUBE 40' | INSIDE LENGTH | 39'5" | 12.01 m | 39'5" | 12.01 m | INSIDE WIDTH | 7'8" | 2.33 m | 7'8" | 2.33 m | INSIDE HEIGHT | 7'10" | 2.38 m | 8'10' | 2.69 m | DOOR WIDTH | 7'8" | 2.33 m | 7'8" | 2.33 m | DOOR HEIGHT | 7'6" | 2.28 m | 8'5" | 2.56 m | CAPACITY | 2,390 ft³ | 67.67 m³ | 2,694 ft³ | 76.28 m³ | TARE WEIGHT | 8,160 lb | 3,701 kg | 8,750 lb | 3,968 kg | MAX. CARGO* | 59,040 lb | 26,780 kg | 58,450 lb | 26,512 kg
|
|
| | OPEN TOP 20' (upgraded also available) | OPEN TOP 40' | INSIDE LENGTH | 19'4" | 5.89 m | 39'5" | 12.01 m | INSIDE WIDTH | 7'7" | 2.31 m | 7'8" | 2.33 m | INSIDE HEIGHT | 7'8" | 2.33 m | 7'8" | 2.33 m | DOOR WIDTH | 7'6" | 2.28 m | 7'8" | 2.33 m | DOOR HEIGHT | 7'2" | 2.18 m | 7'5" | 2.26 m | CAPACITY | 1,136 ft³ | 32.16 m³ | 2,350 ft³ | 66.54 m³ | TARE WEIGHT | 5,280 lb | 2,394 kg | 8,490 lb | 3,850 kg | MAX. CARGO* | 47,620 lb | 21,600 kg | 58,710 lb | 26,630 kg |
| |
| | REEFER 20' | REEFER 40' | INSIDE LENGTH | 17'8" | 5.38 m | 37'8" | 11.48 m | INSIDE WIDTH | 7'5" | 2.26 m | 7'5" | 2.26 m | INSIDE HEIGHT | 7'5" | 2.26 m | 7'2" | 2.18 m | DOOR WIDTH | 7'5" | 2.26 m | 7'5" | 2.26 m | DOOR HEIGHT | 7'3" | 2.20 m | 7'0" | 2.13 m | CAPACITY | 1,000 ft³ | 28.31 m³ | 2,040 ft³ | 57.76 m³ | TARE WEIGHT | 7,040 lb | 3,193 kg | 10,780 lb | 4,889 kg | MAX. CARGO* | 45,760 lb | 20,756 kg | 56,276 lb | 25,526 kg |
| | | | FLAT RACK 20' | FLAT RACK 40' | INSIDE LENGTH | 18'5" | 5.61 m | 39'7" | 12.06 m | INSIDE WIDTH | 7'3" | 2.20 m | 6'10" | 2.08 m | INSIDE HEIGHT | 7'4" | 2.23 m | 6'5" | 1.95 m | TARE WEIGHT | 5,578 lb | 2,530 kg | 12,081 lb | 5,479 kg | MAX. CARGO* | 47,333 lb | 2,530 kg | 85,800 lb | 38,918 kg |
| |
| | FLAT RACK COLLAPSIBLE 20' | FLAT RACK COLLAPSIBLE 40' | INSIDE LENGTH | 18'6" | 5.63 m | 39'7" | 12.06 m | INSIDE WIDTH | 7'3" | 2.20 m | 6'10" | 2.08 m | INSIDE HEIGHT | 7'4" | 2.23 m | 6'5" | 1.95 m | TARE WEIGHT | 6,061 lb | 2,749 kg | 12,787 lb | 5,800 kg | MAX. CARGO* | 61,117 lb | 27,722 kg | 85,800 lb | 38,918 kg |
|
|
| | PLATFORM 20' | PLATFORM 40' | INSIDE LENGTH | 19'11" | 6.07 m | 40'0" | 12.19 m | INSIDE WIDTH | 8'0" | 2.43 m | 8'0" | 2.43 m | INSIDE HEIGHT | 7'4" | 2.23 m | 6'5" | 1.95 m | TARE WEIGHT | 6,061 lb | 2,749 kg | 12,783 lb | 5,798 kg | MAX. CARGO* | 52,896 lb | 23,993 kg | 66,397 lb | 30,117 kg |
|
|
|
